Eskon EPA 100 - 2 Technical Specifications; Electrical Specifications

4
2. TECHNICAL SPECIFICATIONS
2.1 ELECTRICAL SPECIFICATIONS
Supply Voltage
24 V
AC/DC
50/60 Hz
85-265 V
AC
50/60 Hz
Power Usage
9 VA / 2,7 Watt Maximum
Sensor Supply Voltage
Pot:
5 V
DC
mV/V:
10 V
DC
0-10V:
24 V
DC
4-20 mA:
24 V
DC
CANopen:
24 V
DC
Max Sensor Supply Current
100 mA
Refresh Rate
3.5 kHz
Resolution
16 bit
Analogue Inputs
Potentiometer, 0-10 V, 4-20 mA
3,33 mV/V, 2mV/V, 2,5mV/V Ratiometric
Relay Outputs
2 Piece 250 V
AC
3A (For Resistive Load) Relay
Serial Communication (Optional)
RS-232, RS-485, USB, CANopen
Analog Outputs (Optional)
0-10 V, 0-5 V, 0.5- 4.5 V, 4-20 mA, 0-20 mA
Analog Output Resolution
12 bit
Connection
2,5 mm2 Socketed Terminals
