Eskon EPA 100 - 3 Connections

7
3. CONNECTIONS
Analog
Outputs
12
13
4-20 mA
Output
4-20 mA
Output
GND
0-10 V
Output
0-10 V
Output
GND
Tare Input
Tare Input
GND
Digital Connections
9
10
11
RS485
A
B
GND
RS232
Rx
Tx
GND
USB HID
USB CONNEKTOR (B Type
FEMALE)
USB VIRTUAL
USB CONNEKTOR (B Type
FEMALE)
CANopen
CAN
HIGH
CAN
LOW
GND
SENSOR
12
13
14
15
16
Potentiometer
See 6.1.1
X
X
1 No
Terminal
2 No
Terminal
3 No
Terminal
4-20 mA İnput
See 6.1.2
X
X
Sensor
Supply
4-20mA
İnput
GND
0-10 V İnput
See 6.1.2
X
X
Sensor
Supply
0-10V
İnput
GND
3,33 mV/V İnput
See 6.1.3
Signal(+)
Signal(-)
Sensor
Supply
X
GND
