Eskon EPA 100 - Mechanical Measurements

5
2.2 MECHANICAL MEASUREMENTS
Dimensions
48 x 48 x 96 mm
Weight
200 gr.
Assembly
It is fixed to the panel with the feet at the top and
bottom.
Operating temperature
0 to 50 °C
Storage temperature
-10 °C to 60 °C
Protection Class
IP60 Front Panel, IP20 Back Panel
