Specifications
Analog output
Jacks.......................................................XLR (2 channel) × 1
RCA (2 channel) × 1
Headphones × 1
Output impedance
XLR ...................................................................100 Ω
RCA....................................................................25 Ω
Maximum output level (1 kHz, with full-scale input)
XLR: 2.45 Vrms (when set to 0 dB with 10 kΩ load)
RCA: 2.45 Vrms (with 10 kΩ load)
PHONES: 20 mW + 20 mW (with 32 Ω load)
Frequency response ............................................5 Hz to 55 kHz
Signal-to-Noise Ratio (S/N) ..............................................115 dB
Total harmonic distortion ...................................... 0.0015% (JEITA)
Digital input
Balanced digital input.................................XLR (5.0 Vp-p/110 Ω) × 1
Coaxial connector......................................RCA (0.5 Vp-p/75 Ω) × 2
Optical digital connector...............OPTICAL (−24.0 to −14.5 dBm peak) × 1
USB port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B connector × 1
Input sampling frequencies ................32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)
Note: The XLR input (only) supports DSD input in ES-LINK (single) format.
Clock sync output
Jack....................................................................BNC × 1
Output frequencies ....44.1, 48, 88.2, 96, 100, 176.4, 192 (kHz/rectangular wave)
22.5792, 24.576 (MHz)
Same frequency as input (when set to THRU)
Output level ..........................Equivalent to TTL levels (with 75 Ω load)
Clock sync input
Jack....................................................................BNC × 1
Input frequencies ........................44.1, 48, 88.2, 96, 100, 176.4, 192 (kHz)
10, 22.5792, 24.576 (MHz)
Input impedance .........................................................75 Ω
Input level ................................Square wave: equivalent to TTL level
Sine wave: 0.5–1.0 Vrms (with 75 Ω load)
General
Power supply
Model for Europe ...........................................AC 230 V, 50 Hz
Model for USA/Canada......................................AC 120 V, 60 Hz
Model for Korea.............................................AC 220 V, 60 Hz
Power consumption .......................................................7 W
External dimensions (W × H × D) (including protrusions)
445 × 106.5 × 356 mm (17 1/2" × 4 2/8" × 14 1/8")
Weight........................................................10.4 kg (22.93 lb)
Operating temperature ..........................................+5°C to +35°C
Operating humidity.............................5 % to 85 % (no condensation)
Storage temperature...........................................−20°C to +55°C
Accessories
Power cord × 1
Owner’s manual (this document) × 1
Warranty card × 1
o Design and specifications are subject to change without notice.
o Weight and dimensions are approximate.
o Illustrations may differ slightly from production models.
