Esoteric E-03 - Block Diagram

10
Block diagram
INPUT1
Input switching MC head amplier RIAA amplier Buer amplier
NF type
CR type
26 dB
MC
MM
40 dB 0 dB
INPUT2
LINE OU
T
Load
switching
Load
switching
RIAA
(low range)
RIAA
(high range)
Load switching
MC load resistance : INPUT 1 = DEMAG (0 Ω), 10 Ω, 50 Ω, 100 Ω, 300 Ω, 500 Ω, 1 KΩ, 10 KΩ
INPUT 2 = DEMAG (0 Ω), 100 Ω, 500 Ω, 1 kΩ, 10 kΩ
MM load capacity : 0 pF, 100 pF, 330 pF
