17
English
SpecificationsMaintenance
Clock outputs
44.1 kHz setting ......................44.1, 88.2, 176.4, 352.8, 705.6 kHz
1.4112, 2.8224, 5.6448, 11.2896, 22.5792 MHz
48 kHz setting ................................48, 96, 192, 384, 768 kHz
1.536, 3.072, 6.144, 12.288, 24.576 MHz
Both settings .........................................100 kHz, 10 MHz
Connectors .......................................................BNC
Output level .........................Rectangular wave: TTL level/75 Ω
Frequency stability ................Within ±0.01 ppm (−20°C to +70°C)
Frequency precision ...........Within ±0.01 ppm (when shipped new)
(ppm = 10
−6
)
Output clock stabilization (approximate time in minutes)
Until oscillator stabilizes after power turned on ..................15
PLL locking time ..................................................1
Master clock input
Input frequency .............................10 MHz (within ±10 ppm)
Connector ........................................................BNC
Input levels ...............................Sine wave: 0.5-1.0 Vrms/50 Ω
Square wave: 1.5-3.0 Vpp/50 Ω
General
Power supply
Europe/Hong Kong model .........................AC 230 V, 50 Hz
U.S.A./Canada model ...............................AC 120 V, 60 Hz
Korea model .......................................AC 220 V, 60 Hz
Power consumption .........................14 W (while warming up)
10 W (when stable)
Dimensions (W × H × D) (including protrusions)
445 × 106.5 × 360 mm (17 1/2” × 4 2/8” × 14 1/8”)
Weight ..............................................10.2 kg (22 1/2 lb)
Operating temperature range ..........................+5°C to +35°C
Included accessories
Power cord × 1
Owner’s manual × 1
Warranty card × 1
0 Specifications and appearance are subject to change without
notice.
0 Weight and dimensions are approximate.
0 Illustrations in this Owner’s Manual might differ slightly from pro-
duction models.
If the surface of the unit gets dirty, wipe with a dry soft cloth. If it
becomes very dirty, dampen a soft cloth slightly with a diluted neu-
tral cleanser and remove any excess fluid from the cloth thoroughly
before wiping the unit.
Q
For safety, disconnect the power cord from the socket
before cleaning.
0 Never spray liquid directly on this unit.
0 Do not use thinner or alcohol as they could damage the surface of
the unit.
0 Avoid allowing rubber or plastic materials to touch this product for
long periods of time, because they could damage the cabinet.
