Esoteric G-02 User Manual

8
Connections
V
Precautions when making connections
0 Complete all other connections before connecting power plugs to power outlets.
0 Read the owner’s manuals of all devices that will be connected, and follow their instructions.
0 For connections other than clock/word sync, refer to the owner’s manuals of the other devices.
0 When using separate components, such as a CD transport and a D/A converter, together, send this unit’s CLOCK OUT signal to
each component.
Super Audio CD
transport, player, etc.
CLOCK SYNC IN
D/A converter, etc.
CLOCK SYNC IN
Reference oscillation
frequency output
(10 MHz)
External reference
signal generator, etc.
50 Ω
BNC coaxial cable
75 Ω
BNC coaxial cable
75 Ω
BNC coaxial cable
Grounding wire
A
B
D
C
Wall socket
