Clock sync input
BNC connector ..................................................... 1
Frequencies that can be input (±15 ppm)
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz,
176.4 kHz, 192 kHz, 10 MHz,
22.5792 MHz, 24.576 MHz
Input impedance ...............................................75 Ω
Input level ...................Rectangle wave: equivalent to TTL levels
Sine wave: 0.5 to 1.0 Vrms (50–75 Ω)
Clock sync output
BNC connector ..................................................... 1
Output level .........................TTL level equivalent (into 75 Ω)
Output frequencies
44.1 kHz, 88.2 kHz, 176.4 kHz, 48 kHz, 96 kHz, 192 kHz
22.5792 MHz, 24.576 MHz
Same as input frequency (when set to through output)
Analog audio outputs
XLR connectors ............................................1 pair (L/R)
RCA connectors ...........................................1 pair (L/R)
Output impedance .........................................XLR: 20 Ω
RCA: 20 Ω
Maximum output level (at 1kHz, 10kΩ load) .............XLR: 5.0 Vrms
RCA: 2.5 Vrms
Frequency response (192kHz PCM) .............5 Hz – 70 kHz (−3 dB)
S/N ratio .......................................................117 dB
Distortion ............................................0.0007% (1 kHz)
General
Power supply
Model for USA/Canada ...............................AC 120 V, 60 Hz
Model for Korea ......................................AC 220 V, 60 Hz
Model for Europe .............................AC 220–240 V, 50/60 Hz
Power consumption .............................................18 W
External dimensions (W × H × D) ...............445 × 107 × 356 mm
(17 5/8" × 4 1/4" × 14 1/8") (including protrusions)
Weight ..............................................11 kg (24 3/8 lb)
Operating temperature ................................+5°C to +35°C
Operating humidity ....................5% to 85% (no condensation)
Storage temperature ................................−20 °C to +55 °C
Included accessories
Power cord × 1
Owner’s manual (this document) × 1
Warranty card × 1
o Design and specifications are subject to change without notice.
o Weight and dimensions are approximate.
o Illustrations in this manual might differ slightly from production
models.
