ESP Aperta - EZTAG3 Wiring Examples

5
EZTAG3 Wiring Example 1
4
3
+
+
+
_
_
_
Red
NC
Black
Green
Purple
Grey
Pink
Electro-magnetic lock Electronic lock
Tag Reader
Indication LEDs
Keypad
Tag Reader
Indication LEDs
Keypad
EZTAG3 Wiring Example 2
Red
Black
Green/White
Purple/White
Yellow
White
Blue/White
Output for
Lock 2
(Volt-free)
N.O
COM
N.C
Speaker connection
for ‘door bell’ facility
(8 0.5w recommended)
Input DC:
+12V - +24V
Input AC:
12V - 24V
or
+
_
Grey
Orange
Pink
Push button
for Lock 1
(N.O)
P.b for Lock 2
(N.O)
Green
Purple
Blue
Output for
Lock 1
(Volt-free)
N.O
COM
N.C
Lock -release time
N.C for
Electro-magnetic lock
N.O for
Electronic lock
Capacitor for
Electro-magnetic lock
Diode for
Electronic Lock
