ESP Ecocent 250T - Dimensions

15 of 34
V 1.0
www.esavep.com
5.3 Dimensions (mm)
TYPE
SIZE
A
B
C
D
E
F
G
H
I
J
K
L
M
N
R
S
ECOCENT 250 T
1535
1070
910
810
580
450
250
52
100
---
---
410
810
910
---
610
ECOCENT 250 T2
1535
1070
910
810
580
450
250
52
100
250
450
550
750
910
350
650
Power
Supply
Hot Water
Outlet ¾”
“
Temp Sensor 1
for outlet
water
Sacrificial
Anode
Coil 1
Inlet ¾”
Temp Sensor 2 for
outlet water
Coil 1
Outlet ¾”
Hot Water
Outlet ¾”
Immersion
Heater
Temp Sensor 3 for
outlet water
Coil 2
Inlet ¾”
Coil 2
Outlet ¾”
Cold Water
Inlet ¾”
“
Drain point
