ESPEC RS232 - Setting RS232 Communication Parameters

d. Selectthe“Systemconfiguration”buttonithasa“A”iconnexttoit(seeFigure4).

e. Pressthe“Menu”buttononthebottomrightofthescreen,thenselect“OP3”(see
Figure5).

f. Changethefollowingsettings(see Figure6):
i. Communication:RS‐232C
ii. LAN:
ON


Ste
p
8.d
Figure4:ServiceScreen
Step 8.e
MenuButton
underhere
Figure5:MenuScreen
Step 8.f.i
Step 8.f.ii
Figure6:SetOptions
