ESPEC RS232 - RS232 Configuration and Finalization; Accessing Configuration Settings



7. Hardwareinstallationisnowcomplete.Closetheelectricalandwaterboxandturnchamber
powerbackon.
8. ConfiguretheP300forRS232communications.
a. Fromthemainscreenselectthe“ChamberSetup”Tab.
b. Selectthe“Configuration”button.
c. Selectthe“Service”button.
i. Whenpromptedenterthe
password“335”,itwillneedtobeenteredtwice.
O
p
tionPanel
Passcablehere.
Figure3:RS232CableRouting
