No. Name Type Function

1 GND G Ground

2 3V3 P 3.3 V power supply

3 3V3 P 3.3 V power supply

4 IO2 I/O/T GPIO2, ADC1_CH2, FSPIQ

5 IO3 I/O/T GPIO3, ADC1_CH3

6 GND G Ground

7 RST I CHIP_PU

8 GND G Ground

9 IO0 I/O/T GPIO0, ADC1_CH0, XTAL_32K_P

10 IO1 I/O/T GPIO1, ADC1_CH1, XTAL_32K_N

11 IO10 I/O/T GPIO10, FSPICS0

12 GND G Ground

13 5V P 5 V power supply

14 5V P 5 V power supply

15 GND G Ground

No. Name Type Function

1 GND G Ground

2 TX I/O/T GPIO21, U0TXD

3 RX I/O/T GPIO20, U0RXD

4 GND G Ground
