No. Name
Type
Function
5
IO9
I/O/T
GPIO9
6 IO8
I/O/T
GPIO8
7
GND
G
Ground
8
IO7
I/O/T
GPIO7, FSPID, MTDO
9
IO6
I/O/T
GPIO6, FSPICLK, MTCK
10
IO5
I/O/T
GPIO5, ADC2_CH0, FSPIWP, MTDI
11
IO4
I/O/T
GPIO4, ADC1_CH4, FSPIHD, MTMS
12 GND
G
Ground
13
IO18
I/O/T
GPIO18
14 IO19
I/O/T
GPIO19
15
GND
G
Ground
P: Power supply; I: Input; O:
Output; T: High impedance.
5
7
Table of Contents
Getting Started
2
Description of Components
2
Required Hardware
3
Software Setup
3
Hardware Reference
4
Block Diagram
4
Power Supply Options
4
Pin Layout
7
4
