NOTES Page 31
NOTES
REPLACING BATTERY
5HL-600 / 5HL-603
ATTENTION
Only use replacement batteries supplied by Esse-ti.
Remove the screw located on the back side of Helpy Compact.
Release the cover by acting on the wings at the top or bottom.
Turn the cover to the right paying attention to the loudspeaker
connection cable.
Disconnect the battery to be replaced and connect the new one.
Replace and close back the cover paying attention to the microphone.
Retighten the screw on the back side.
EU DECLARATION OF CONFORMITY
Hereby, Esse-ti S.r.l. declares that the equipment type Helpy Compact is in
compliance with Directives 2014/33/EU - 2014/53/EU.
The full text of the EU declaration of conformity is available from the
following Internet address:
https://www.esse-ti.it/en/dichiarazioni-di-conformita
