System
installation
2.48
LAMP
TEST
•
Activates
remote
annunciators.
ENABLE/DISAB
switch
functions.
a[1
LEDSOntheLSS4
master
paneland
alI
LE
KEY
SWITCH
-
Enablesrhe
RSA4-COM
front
panel
Whenju
mperJP1(onthe
RSA4-COM)
is
installed
the
ENABLED
settine,
it
annunciatesa
Trouble
w'hich
indicates
that
CJ
Switch
onthe
RSA4-COM
module
is in the
DISABLED
pos
ition.
jumperJP1
is
installed
in the
DISABLED
setting•, a
DISABLED
key
Switch
willNOT be
annunciatedatthe
control
panel.
POWER
-
GreenLED
indicates24 VDC
power
is
availableatthe
annunciator.
in
the
If
ALARM
- Red LED
Indicatesthe
LSS4
master
panelhas
detecteda
fire
alarm
condition.
S
UPERVISORY
-
YellowLED
indicatesthe
LSS4
master
panelhas
detecteda
supervisory
condition.
TROUBt.E
-
YellowLED
indicatesthe
LSS4
master
panelhas
detecteda
troublecondition.
ZONE
i_EDs
- Red
LEDs
indicatethe
locationofthe
fire
alarm.
BUZZER
-
Internal
buzzer
indicatestheLS S4
master
panelhas
detected
a
trouble
condition.
t•O1
(I.INE)
- Red LED on
RSA4-CPU
board
indicates
data
channel#1
active
whenON,and
data
channel#2
active
when
OFF.
kO2
(TXD)
- Red LED on
RSA4-CPU
board
indicates
data
transmission
on
either
channel#1or
channel#2.
LSS4
Installation,
Operation,and
Maintenance
Manual
