ETAS MDA V8.6 User Manual

ETAS 5 Instruments
1. To merge signals to one strip, right-click the desired signals from
different strips.
2. Click Move to New Strip.
or
1. To move signals to separate strips, right-click the desired signals
from one strip or different strips.
2. Click Move to Individual Strip(s).
To delete a strip
1. Open the context menu of the strip that you want to delete.
2. Select Delete Strip.
Note that a strip is also deleted when the last signal of a strip is removed.
5.2.5 Using Axes
You can perform the following actions:
l
"To assign signals using the selection wheel" below
l
"To use common axes" on the next page
l
"To use individual axes" on the next page
l
"To scroll axes" on page92
l
"To scroll the time axis" on page92
l
"To zoom axes" on page92
l
"To adjust the axis range manually" on page92
l
"To predefine an axis range for a signal" on page93
l
"To set the default behavior for signal-to-axis assignment" on page94
l
"To delete axes" on page94
To assign signals using the selection wheel
To assign signals to an oscilloscope, you can use the selection wheel. It
appears when signals are assigned to an oscilloscope or moved within an
oscilloscope via drag and drop.
1. Drag the signals into the analog graphical area of the oscil-
loscope or to the desired position in the signal list. After a short
delay the selection wheel appears.
2. Within the selection wheel, drop the signals onto one of the
options:
MDA V8.6 – User Guide 90
