ETC ColorSource Linear - Page 17

ETC Installation Guide
ColorSource Linear v1.7
RDM Values
Parameter Fixture Value Description
Manufacturer ID All 0x6574 Electronic Theatre
Controls
Model ID Linear 1 0x0209
Linear 1 Deep Blue 0x020A
Linear 2 0x020D
Linear 2 Deep Blue 0x020E
Linear 4 0x0211
Linear 4 Deep Blue 0x0212
DMXStart Address All 0x00F0 Range = 1–512
DMX Personality Linear 1 0x00E0 1 = 5 Channel
2 = Direct
3 = 1 Channel
4 = RGB
Linear 2 in Group
mode
Linear 4 in Group
mode
Linear 2 in Cell mode 5 = 5 Channel Multi-Cell
6 = Direct Multi-Cell
7 = 1 Channel Multi-Cell
8 = RGB Multi-Cell
Linear 4 in Cell mode
Output Frequency Linear 1 0x8123 0 = Standard (1.2 kHz)
1 = High (25 kHz)
Linear 2 in Group
mode
Linear 4 in Group
mode
ColorSource Linear Page 17 of 20 ETC
