Typical Power Consumption
Linear 1
100 V 120 V 230 V
Power Current Power Current Power Current
Idle 1.63 W 0.03 A 1.55 W 0.03 A 1.43 W 0.03 A
Direct at Full 107 W 1.07 A 105 W 0.88 A 104 W 0.46 A
Linear 2
100 V 120 V 230 V
Power Current Power Current Power Current
Idle 2.86 W 0.06 A 2.98 W 0.06 A 2.56 W 0.06 A
Direct at Full 210.83 W 2.12 A 208.67 W 1.75 A 204.5 W 0.91 A
Linear 4
100 V 120 V 230 V
Power Current Power Current Power Current
Idle 5.28 W 0.11 A 5.24 W 0.11 A 4.65 W 0.12 A
Direct at Full 424.17 W 4.27 A 419.33 W 3.52 A 409.17 W 1.82 A
Accessories
You can use several half-meter optional accessories with ColorSource
Linearfixtures, including:
•
Secondary lenses (horizontal, vertical, and round)
•
Barn doors (7414K1020)
•
Louver (7414K1019)
For information on installing secondary lenses, see Install Secondary Lenses
on page15 .
Accessories for Linear 2 and Linear 4
For the Linear 2 and Linear 4 fixtures, order one accessory for each 0.5meter
segment (cell) of the fixture. For example, for a Linear 2 fixture, order two barn
door accessory kits to fit the full length of the fixture.
Spacers for secondary lenses are included with the fixture. Use these spacers
to hold the accessories in position when multiple lenses are used in the Linear
2 and Linear 4 fixtures. The spacers are positioned between the 0.5 meter
lenses.
Contact your local dealer for more information.
