Connect to the Eos Family Console
You can configure your events in the Eos family console from the Show Control Display tab.
1. Connect an Ethernet cable to the Ethernet port on your Analog IO Gateway and then connect
the cable to a network switch on your Eos console’s lighting network.
2. If the port on the switch is not PoE, you can use an external DCpower supply (provided
separately) to provide power.
3. To confirm that the gateway is connected to your Eos family console, navigate to the About
screen and the gateway should appear in the list of network connected devices.
4. You can now integrate your gateway analog inputs or relay outputs into your Eos show file:
Analog Inputs can be programmed from the Show Control tab. Note that the Source field in
your Analog event must be set to the same value as your gateway’s Analog Group ID, which
can be configured from the Net3 Concert application.
Relay Outputs can be programmed as External Links from the Cue List.
Note:
For additional information on programming analog inputs or relay outputs on your
Eos family console, refer to the Eos Family Operations Manual.
