1 Unpack and Organize 3
Section 1
Unpack and Organize
The table below lists the parts and components needed to retrofit a Sensor rack up to a
Sensor+ rack with a CEM+. Each part is listed to reflect the different quantities for the
different kits and types of racks.
Parts/Components
ETC Part Number
SR6
7150K1001
SR12
7150K1002
SR24
7150K1003
SR48
7150K1004
Parts Included in the Kits
Shipped Assembled
CEM+ Backplane Bracket
7150A3002
1111
CEM+ Backplane PCB Assy
7150B5003
1111
CEM+ Backplane Label
7150A4005
1111
Stand-off (4-40x.375 M-F 3/16-HX AL)
HW9322
6666
CEM+ Backplane Short Shield
7150A3007
1111
Screw (4-40X1/4 SEMS PhPHMS)
HW183
8888
Shipped as Individual Parts
CEM+ Sensor Rack Retrofit Manual (this manual)
7150M2300
1111
Backplane Screw (8-32X3/8 PhPHMS)
HW377
2222
CEM+ Backplane 1/8” #8 screw spacer
HW9343
2222
Wire tie - 4”
HW7121
881014
Tie-mount (sticky-back)
HW741
4444
Ethernet Termination Kit
4101A2003
1111
CAT5 Cable RJ45/RJ45 UTP 1FT
N4036
1111
Sensor+ Beacon (Blue LED) PCB Assy
7050B5109
1111
Beacon PCB Screw (6-32X3/8 PhPHMS)
HW222
2222
Sensor+ Beacon Door Acylic
7051A4116
1111
Terminal Block 8F Plug Screw
J3407
2222
CEM+ UPGRADE 16-PIN Power Cable
7150B7002
1111
PCB Upgrade 16-Pin Power
7150B4009A
1111
CEM+ Lower Ribbon Card Assy
7150B5006
1112
CEM+ Upper Ribbon Card Assy
7150B5007
12
Sensor+ Door Label
7151A4001
1111
Heat shrink - 4.5” x 1.5” dia.
W682
1111
Heat shrink - 6” x 3/16” dia.
W606
1111
