-7-
Peak Hold
Push HOLD without release, the meter will
show the peak value during the pushing period
Reading Hold
DH indicating the reading is hold
Out of Range
OL indicating the current is out of range
Auto Power-off
5 Minutes after power on, it will power off
automatically to lower the power consumption
Battery Voltage
Indicating the battery voltage is lower then
7.2V.Then the battery have to be changed
Weight
120g（including the battery）
Consumption About 5mW
Temperature
and Humidity
Working: 0℃～40,below 80%rh℃
Storage: -10℃～60,below 70%rh℃
Insulating
Strength
AC2kV/rms (between the alloy of the clamp
and the housing)
Applicable
Safety Rules
IEC1010-1、IEC1010-2-032、pollution, etc 2、
CAT Ⅲ(600V)
