ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05 Chapter E: Appendixes
Operation & Software Manual
Direct Drives & Systems 329
DSCDL monitorings
42
Position captured on digital input (see K182/K178/
K179). This bit is set when the conditions of the digital
input allow the capture of the position. It is reset when 1
is written in K182
256 8
User bit 0, could be modified by trigger functions or by
K177
512 9
User bit 1, could be modified by trigger functions or by
K177
1024 10
User bit 2, could be modified by trigger functions or by
K177
2048 11
User bit 3, could be modified by trigger functions or by
K177
4096 12
User bit 4, could be modified by trigger functions or by
K177
8192 13
User bit 5, could be modified by trigger functions or by
K177
16384 14
User bit 6, could be modified by trigger functions or by
K177
32768 15
User bit 7, could be modified by trigger functions or by
K177
M63 TEB status 524288 0 4294967295
10
User word bit 0, could be modified by trigger functions or
by K177
21
User word bit 1, could be modified by trigger functions or
by K177
42
User word bit 2, could be modified by trigger functions or
by K177
83
User word bit 3, could be modified by trigger functions or
by K177
16 4
User word bit 4, could be modified by trigger functions or
by K177
32 5
User word bit 5, could be modified by trigger functions or
by K177
64 6
User word bit 6, could be modified by trigger functions or
by K177
128 7
User word bit 7, could be modified by trigger functions or
by K177
256 8
User word bit 8, could be modified by trigger functions or
by K177
512 9
User word bit 9, could be modified by trigger functions or
by K177
1024 10
User word bit 10, could be modified by trigger functions
or by K177
2048 11
User word bit 11, could be modified by trigger functions
or by K177
4096 12
User word bit 12, could be modified by trigger functions
or by K177
8192 13
User word bit 13, could be modified by trigger functions
or by K177
16384 14
User word bit 14, could be modified by trigger functions
or by K177
32768 15
User word bit 15, could be modified by trigger functions
or by K177
65536 16 The controller is in power on
M Alias Values
Bit #
<P1>
Comment for monitorings M
and <P1> of the DSCDL
Def. Val
<P1>
Min. Val
<P1>
Max. Val
<P1>
