Etesia MBHE2 - TROUBLESHOOTING; MOVING MOWER AND TOWING PROCEDURES; TRANSPORT AND TYRE CHANGING

32
12•1 MOVING THE MOWER WITH
THE ENGINE SWITCHED OFF
• The by-pass enables the mower to be moved without switching on the
engine.
• Put the lever on [0] position: unclutched position to move the mower
with engine on stop.
• To gain access to the by-pass lever, open the grassbox in emptying
position. On MKM, the by-pass lever is located on the rear cover.
(see pictures 5 and 5a)
Do never use the mower with a disengaged by-pass (position 0).
12•2 TOWING THE MACHINE IN THE
EVENT OF BREAKDOWN
• Disengage the box (see paragraph 12•1).
• Close the fuel tap (see paragraph 7•5•2 and 8•6).
• Set up the towing hock:
8QVFUHZWKHIURQWEXPSHU¿[DWLRQVFUHZVDQGWDNHLWRXWVHHSLF-
WXUHD7KHWRZLQJULQJLVORFDWHGEHKLQGWKHEXPSHU,WLV¿[HG
on the back side on the frame tube (see a picture 37a).
- Unscrew the towing ring screws, return it so that the ring looks
WRZDUGVWKHIURQWDQG¿[LWZLWKWKHVDPH¿[DWLRQVFUHZV
- Drill 2 holes diameter 12 mm at the back of the bumper and cut in
order to obtain a circle hole (see picture 37b).
- Put the bumper back into place. The towing ring is going through
the circle hole.
Use only a towing bar.
Do not use other towing points.
WARNING!
The disengaged position should be used only for travel over
short distances at low speed (up to 5 km/h). After moving the
mower, remember to place the lever in the engaged position.
• Where a broken-down mower is to be moved over long distances,
an appropriate form of transport (trailer, goods vehicle) should be
used.
12•3 TRANSPORT
For any delivery on a trailer or in a van:
- Transporting your mower, use straps and pass around strap hooks
(rep. 12 description page 9) and towing hook.
- Engage parking brake.
- Stop the engine.
- Remove the ignition key.
- Close the petrol tap.
- Block wheels.
12•4 CHANGING TYRES
:KHUHLWLVQHFHVVDU\WRUHPRYHDZKHHOWKLVVKRXOGEHGRQHRQ¿UP
even ground.
• Do not attempt to carry out work on or under the mower if it has
been raised on temporary supports or without taking proper safety
precautions.
• If you do not possess appropriate tools or the knowledge needed to
carry out the work, contact your dealer.
• Remove the wheels in the following manner:
• FRONT WHEELS
- Switch off the engine and remove the ignition key.
- Apply the parking brake.
- Secure the vehicle using chocks.
- Place a jack under the front axle on the side where the wheel needs
to be replaced and lift until this wheel does not touch the ground
anymore (see picture 38a).
- Secure the machine by lying it on stable props.
- Remove the wheel hub.
- Remove the circlips with the help of a screwdriver (see picture 38b).
You can now remove the wheel from the shaft.
• For remounting, follow the same instructions in the opposite way. Do
grease the wheel shaft.
12• TROUBLESHOOTING
11• PROLONGED STORAGE - WINTER STORAGE
11•1 PREPARATION FOR THE WINTER
STORAGE
• Clean the machine thoroughly, and the cutter plate in particular.
• Lubricate moving parts and change the engine oil.
• Drain the fuel tank completely and run the engine until all the fuel
is used up.
Always empty the fuel tank in open air.
• Disconnect the spark plug.
• Remove the spark plug and inject a small quantity of oil (1 cl) into the
cylinder(s) via the plug opening.
• Activate the engine by turning the ignition key.
• Replace the spark plug by hand without replacing the suppressor.
5HPRYHWKHEDWWHU\E\¿UVWGLVFRQQHFWLQJWKHQHJDWLYHWHUPLQDO
• Charge the battery: see section 9•5•2.
• Store the battery in a dry, well-ventilated and frost-free place.
• Recharge the battery every two months.
• Always keep the battery out of the reach of children.
• Contact your dealer for the following adjustments or maintenance
operations:
- Adjustment of the parking brake
- Adjustment of the cutter plate alignment
- Adjustment of the steering
- Adjustment of the engine
- Replacement of belts, where necessary
- Replacement of any parts, or repairs involving the removal of parts
which are not covered by this manual.
11•2 RETURN TO SERVICE
• Unscrew the spark plugs and clean them with petrol. Allow to dry but
do not put them back for the time being.
• Reinstall and reconnect the battery.
2SHUDWHWKHVWDUWHUYHU\EULHÀ\XVLQJWKHLJQLWLRQNH\WRHOLPLQDWHDQ\
excess oil from the cylinders.
7KHQ¿WWKHGU\VSDUNSOXJVDQGFRQQHFWWKHFDSV
• Check the oil level and top up with fuel.
You are now ready to restart the engine.
