2• KEY TO DIAGRAMS - USE
• ENGINE SPEED
• Indications for controlling the engine speed:
START: position for starting the engine
MAXI: engine at full speed
MINI: engine idling
• STARTING THE ENGINE
0: engine off, power switched off
I: power switched on
:
engine started
• PARKING BRAKE
• The arrow indicates the direction of movement
of the brake lever in order to engage the parking
brake.
• CUTTING HEIGHT
• Indicates the cutting height.
• EMPTYING THE GRASS BOX
• On every models except MKM:
The arrow indicates the direction of movement
of the release lever in order to empty the grass
box.
• OPERATING THE CUTTER
I: cutter switched on
0: cutter switched off
• CONTROL SWITCH « MOW IN REVERSE »
Once the cutter is in operation, press this
switch once to mow with the machine in
reverse.
Otherwise the cutter disengages as soon as
you select reverse. It will re-engage with the
advance lever when it reaches Neutral or
Forward.
If you disengage the cutter with the engage
cutting system switch or if a safety feature
trips it, you will have to re-engage the cutter.
• BY-PASS
1: Lever on I position: closed by pass = advance transmission
engaged
0: Lever on O position: open by pass = advance transmission
disengaged
• LIGHTING (MKHP)
• HORN (MKHP)
