Ethnicraft Spindle Bed - Connecting Siderail and Head;Footboard; Step 1: Attach Siderail to Headboard; Connecting Center Leg to Center Support; Step 2: Assemble Center Support System

2 / 5
6
5
CONNECTING SIDERAIL AND HEAD / FOOTBOARD
A.
B.
CONNECTING CENTER LEG TO CENTER SUPPORT
- USE DOWEL Ø12x50 (8X)
- USE HALFMOON BOLT M8x100 (4X)
- USE HALFMOON WASHER (4X)
- TIGHTEN FULLY
4
1 2
3
5
1
4
1
1 2
3
- USE JF SCREW M6x50 (1X)
- TIGHTEN FULLY
1
4
(L)
4
(R)
3
ATTACH SIDERAIL
WITH DRILL HOLE
TO HEADBOARD
TEAK SPINDLE BED - QUEEN SIZE - WITH SLATS
ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION
