3
Features
Item Description
1
Y/
a or Accept Button - Push type button used to accept or confirm a
selection from a menu, advance to the next screen, or provide a “yes”
answer.
2
Directional Button - Thumb pad rocker type buttons used to move the
highlight/focus on the screen up, down, left, and right, as indicated by the
arrows.
3
N/X or Cancel Button - Push type button used to exit a menu or
program, return to the previous screen, or provide a “no” answer.
4
Shortcut Button - Push type programmable button used to perform a
variety of routine tasks.
5
Power (On/Off) Button - Push type button used to turn the ETHOS Tech
on and off. For emergency shutdown, press and hold for 5 seconds.
6 Touch Screen - Allows you to quickly navigate menus and perform tests.
7
Mini USB Jack - USB cable connection used to transfer saved data files
to a personal computer.
8
Micro secure digital (uSD) Card - Contains operating system
programming. IMPORTANT
The uSD card must be installed to
operate the diagnostic tool. Do not remove the uSD card while the
diagnostic tool is turned on.
9
Data Cable Connector - Data cable connection used to connect the
ETHOS Tech to a vehicle data link connector (DLC).
10
Power Supply Adapter - Used to connect the AC/DC power supply to
the ETHOS Tech.
11
Hand Strap (Optional) - A hand strap can be added, to make it easy to
hold and carry the ETHOS Tech with one hand.
12
Built-in Stand (Optional) - A built-in stand can be added for tabletop use.
The stand extends from the back of the ETHOS Tech and clips into place
for storage.
13
Battery Cover - The ETHOS Tech can be powered using 6 AA type
batteries.
AC/DC Power Supply (not shown) - The ETHOS Tech can be powered
from a standard AC outlet using the supplied AD/DC power supply.
