eufy Security HomeBase 2 User Manual

10
English English
11
Option 2 - Doorbell Wire Powered
1. If you have existing and working doorbell wiring at the front door, the doorbell
will be powered by the wires constantly. So you don’t need to detach and charge
it after installation.
2. Since the doorbell is connected to the wires, the mounting position is limited.
3. If you choose this option, please jump to
Appendix 3 Powering the Doorbell
with Doorbell Wires
.
8 - 24V AC Doorbell Wiring
STEP 4 FINDING A MOUNTING SPOT
Find a Mounting Spot
Take the video doorbell to your front door and check the live view on the App at the
same time. Find a location where you can get the desired field of view.
Consider the below factors:
1. Check if you can reuse the existing holes and anchors on the wall or door frame.
2. If you want to place the doorbell close to a side wall, make sure the wall doesn’t
show up in the field of view. Otherwise IR light will be reflected and night vision
will become blurry.
3. If you are drilling the mounting holes for the first time, the recommended
mounting height is 48" / 1.2 m from the ground.
4. Use the 15° mounting wedge as a supplementary mounting bracket if you wish to
see more on a specific side.
1.76m(5’9”)
1.2m (48")
0.3m
(12")
1m
(40")
15°
Without 15° Mounting wedge With 15° Mounting wedge
Door
Door
Video Doorbell
Video Doorbell

eufy Security HomeBase 2 Specifications

General

Storage	16GB eMMC
Model	T8010
Expandable Storage	No
Connectivity	Ethernet, Wi-Fi
Compatibility	eufy Security devices
Wireless Range	300 ft (open area)
Operating Temperature	-10°C to 45°C
Operating Humidity	0% to 95% (non-condensing)
