Sound level of the room the camera is in
Time
Status of the monitor battery
6. Placing the Camera
The camera can be placed on a table or shelf, or can be installed on a wall or crib.
Select a location and height that achieves your desired view and is within reach of a power outlet. Use the monitor to test
the viewing angle from your desired mounting spot.
6.1 On the Wall
8 ft
9 ft
5.6 ft
Follow the steps below to mount the camera on the wall.
• Disconnect the camera from the power outlet before mounting.
1. Place the mounting plate against the wall, matching the direction as UP indicates. Mark the screw holes with a pencil.
2. Drill holes into the wall and then insert anchors into the holes. Anchors are not needed for wooden walls.
To Next Page
