3. Align the mounting plate with the threaded screw receptacles of the exterior keypad.
Tightly fasten the screws in
place. Set the screws with
your hands, then use a
screwdriver to secure them.
4. Plug the power cable (large connector) and then the radar cable (small connector) into the sockets on
the back of the interior assembly.
Route the cables around the tailpiece receiver to avoid pinching during installation.
To disconnect the radar cable, gently pull the tab.
