Disconnect the camera from the power outlet before mounting.
We recommend mounting the camera 7-10 ft (2-3 m) above the
ground. This height maximizes the detection range of the camera.
• The camera can be mounted both indoors and outdoors. Avoid
mounting the camera under direct sunlight.
Camera
Field-of-View
Up to 33 ft (10 m)
7-10 ft
(2 - 3 m)
MOUNTING YOUR CAMERA
Select a Location and a Height
Select a location that is within reach of a power outlet. If the distance
exceeds 16.4 ft (5 m), please consider a separately sold extension
cable.
≤16.4 ft (5 m)
Make sure the camera receives a strong signal from the S380
HomeBase in the location you want to mount it to achieve a smooth
video stream in the app.
