Operating Manual
www.esglobal.co.kr
9
Ⅱ. Operation
II -2. Cavitation (Body)
⑧ Start Button
① Type of
Handpiece
⑨ Select Handpiece Type
⑦ Select
Hapdpiece Type
② Cavitation
③ Control
Time Button
⑤ Preset Timer
① Type of handpiece: Displays the current operation handpiece.
② Cavitation : Cavitation operating button (Level : 1~10 step)
③ Control Time Button: Adjusts operation time button (1~30 min)
④ Pulse Program Button: Selects the pulse program. (4 mode: C , P1 ,P2 ,P3)
⑤ Preset Timer : Shows total treatment time
⑥ Display Power Level: Shows the current power level of cavitation.
⑦ Select Handpiece Type
⑧ Start Button : Start/Stop Button
⑨ Select Handpeiece Type
⑥ Display Power Level
15:00
④ Pulse Program Button < C , P1 ,P2 ,P3 >
