Once the washing operation is completed, clean the squeegee and check the integrity of the blades.
Proceed as follows:
• Lift the brush plate and turn off the switch on the control panel;
• Lift the squeegee using the provided lever and turn off the switch on the control panel after 10
seconds;
• Stop the machine in a levelled area;
• Turn the key to position 0;
• Unscrew both fixing knobs (pos. 1) and remove the squeegee vacuum pipe (pos. 2);
• Remove the squeegee; lay it on the ground facing up (as shown in the figure). Use water to wash and clean the lower
part and the mouth of the squeegee (pos. 3), removing any pieces or encrustations for better vacuum performance;
• Use a piece of cloth to wipe off the rear drying blade (pos. 4) and the front drying blade (pos. 5);
• Make sure the blades are in good condition and if necessary rotate them in order to have a new edge in contact with
the floor.
REPLACING SQUEEGEE BLADES
The squeegee is fitted with two drying blades (a rear and a front blade) as specified in the previous paragraph.
Each blade has 4 edges that can be used and rotated 4 times before being replaced, unless one of the edges is torn.
For better drying performance, make sure the edge of the rear blade in contact with the floor is not worn out. If the blade
is worn out, rotate it or replace it.
