E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 30/41
The stopgap control panel is located at the front of the electric box.
To reach it, take off the hood nosing, unscrew the 4 butterfly screws and remove the protection plate.
OPTION : MINICOM (Backup controller)
TO BE USED ONLY AS STOPGAP SOLUTION
Exhaust vent control
(damper)
Steam Injection key
Thermostat
Switch-inverter
Indicator light brights when the oven heats
Setting point of the
thermostat
