EuroLite LED KLS Scan Next FX User Manual

00132156, Version 1.0
33/56
DESCRIPTION OF THE DEVICE
Front
1
Fixation screws
2
Mounting bracket
3
Scanners
4
Infrared sensor for the remote control
5
LED derby
6
Safety eyelet
7
UV LEDs
8
LED spots 1-4
9
TV spigot
Rear
10
P-Con power feed-through output
11
Fuse holder
12
P-Con power input
13
DMX output
14
DMX input
15
QuickDMX USB port
16
OLED display and operating buttons
17
Infrared sensor for the remote control
18
Sensitivity control for the microphone
19
Microphone for sound-controlled operation
1 2 3 4 5 6
7
9
2 1
3
8
7
8
11 12 13 14 15 16 17 18 1910
T2A/250V
Compact Light Set
LED KLS Scan
DMX512
T =45°C
T =65°C
a
c
Steinigke Showtechnic GmbH Andreas-Bauer-Str. 5·
97297 Waldbüttelbrunn Germa www.steini ke.deny g
·
No. 42109897 EAN 4026397690064∙
CONTROL
100-240V~ 50/60Hz / 115W

EuroLite LED KLS Scan Next FX Specifications

General

Brand	EuroLite
Model	LED KLS Scan Next FX
Category	Flood Light
Language	English
