OPERATION
The built-in control panel of the unit features four operating buttons and a display which shows all operation
statuses. After connecting the unit to the mains it requires a short initialization process and is then ready for
operation. The display shortly indicates the firmware version followed by the last operating mode. The light
set may be controlled via IR remote control or a DMX controller. The operating modes can be selected by
means of the display and the control buttons.
Operating buttons
Button Function
MENU
Selects the operating mode or returns to the initial screen.
ENTER
Activates a value to be modified or saves a value when modifying.
UP
Selects the next menu item or increases values when modifying.
DOWN
Selects the previous menu item or decreases values when modifying.
Menu structure
Mode Display Function
Automatic mode
AUTO
Program 1-20
Show program 1-20
Fade ON/OFF
Color fade on/off
Speed 1-99
Running speed 1-99
Dimmer 0-255
Brightness 0-255
Sound control
SOUND
Program 1-20
Show program 1-20
Fade ON/OFF
Color fade on/off
Dimmer 0-255
Brightness 0-255
Manual mode
Manual
Par 1
Red 0-255
Red 0-100%
Green 0-255
Green 0-100%
Blue 0-255
Blue 0-100%
White 0-255
White 0-100%
Par 2
Red 0-255
Red 0-100%
Green 0-255
Green 0-100%
Blue 0-255
Blue 0-100%
White 0-255
White 0-100%
Par 3
Red 0-255
Red 0-100%
Green 0-255
Green 0-100%
Blue 0-255
Blue 0-100%
White 0-255
White 0-100%
Par 4
Red 0-255
Red 0-100%
Green 0-255
Green 0-100%
Blue 0-255
Blue 0-100%
White 0-255
White 0-100%
Derby
Red 0-255
Red 0-100%
Green 0-255
Green 0-100%
Blue 0-255
Blue 0-100%
Motor 0-255
Rotation speed 0-255
