EuroLite LED ML-56 COB PCL 100W User Manual

00085615.DOC, Version 1.0
24/28
Control Board
The Control Board offers several features: you can simply set the starting address, run the pre-programmed
program or select a DMX channel mode.
Browse through the menu by pressing Menu. Press Enter in order to select the desired menu. You can
change the selection by pressing Up or Down. Press Enter in order to confirm. You can leave every mode by
pressing Menu. The functions provided are listed in the following sections.
Menu Sub menu Description
STAT
R.000 000-255
Dimmer intensity of LED colors
Strobe effect 0 – 20 (increasing)
G.000 000-255
B.000 000-255
Y.000 000-255
W..000 000-255
ST.00 00-20
AUTO
AT.01 01-10
A
utomatic programs
User defined automatic programs (s. EDIT)
PR.01 01-10
SOUD
MOD1
Sound controlled program (color change)
MOD2
Sound controlled program (strobe)
RUN
DMX
DMX controlled mode
SLAV
Slave mode
DMX d001-255
DMX address setting
Default setting：001
PERS
STRG
Setting DMX channel mode
STRG：7 DMX channels (default setting)
ARC.1：5 DMX channels
AR1.D：8 DMX channels
AR2.5：11 DMX channels
HSV.：3 DMX channels
ARC.1
AR1.D
AR2.5
HSV.
TEMP CURR
Temperature inside of the device
EDIT PR.01-
PR.10
SC.01-
SC.30
R.000 (000-255)
Red
With this function, you can edit the user defined
automatic programs (PR.01-PR.10), which can be
called up under AUTO.
Each program (PR) with 30 scenes (SC.01-SC.30),
each scene with 8 steps (R/G/B/Y/W/ST/T/F).
G.000 (000-255)
Green
B.000 (000-255)
Blue
Y.000 (000-255)
Amber
W.000 (000-255)
White
ST.00 (00-20)
Strobe
T.000
Duration of the scene
F.000
Fade time of the scene
SET
UPLD
Transfer of the user defined automatic programs
(PR.01-PR.10) to another device (password is up-
down-up-down-enter)
REST
Reset (password: Up-Down-Up-Down-Enter)
RGBW ON/OFF
Use or nonuse of the white balance values of CAL2
POW HIGH/NORM
Power limitation (HIGH:100 %, NORM: 33%)
DIM
OFF
Dimmer speed (step response)
Off : Response characteristics of LEDs
DIM 1: Response characteristics of halogen lamps,
fast
DIM 2: Response characteristics of halogen lamps,
middle
DIM 3: Response characteristics of halogen lamps,
slow
DIM 4: Response characteristics of halogen lamps,
very slow
DIM1
DIM2
DIM3
DIM4
