CAUTION
Make sure that the main voltage is the same as indicated on the idencaon
label of the device. All electrical connecons must stay dry under all
circumstances.
Installaon video
1. Scan the QR code (Figure 22) to open
the video. This video demonstrates the
installaon of this device.
Figure 22.
Outdoor unit installaon
1. Aach the boom caravan brackets
(Figure 23,pos.2) to the outdoor unit
(Figure 23,pos.1) by ghtening two screw
caps per bracket (Figure 23,pos.3).
2. Hang the outdoor unit (Figure 23,pos.1)
in the desired window, make sure the
indoor unit is securely placed on a table or
couch seat.
3. Tighten the adjustment bolt (Figure
23,pos.4) per bracket. Make sure the
bumper (Figure 23,pos.5) is placed
vercal.
Figure 23.
26
