EUROM AC2401 E - Indoor Unit Installation; Support Brackets (Optional)

4. If needed, use the removable block (Figure
24,pos.4) on thinner walls or window
frames.
5. Make sure the outdoor unit (Figure
24,pos.1) hangs level by ghtening the
nut (Figure 24,pos.2) on the adjustment
bolt spacer . Make sure the bumper
(Figure 24,pos.3) is placed vercal.
Figure 24.
Indoor unit installaon
The indoor unit can be placed on a sturdy table or it can be placed hanging on support brackets.
Support brackets (oponal)
1. Aach the top caravan brackets (Figure
25,pos.1) to the boom caravan brackets
by ghtening the screw cap per bracket
(Figure 25,pos.2).
Figure 25.
27
