5
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org
Product Overview
1 Safety guards
(front and rear grilles)
2 Fan blade
3 Clamping ring
4 Lock system of the
clamping ring
5 Control panel
6 LED display
7 Fan body securing knob
8 Upper column
9 Column securing knob
10 Lower column
11 Stand base
12 Base locking lever
13 Remote control
NOTE: Due to continued product
improvement, images and
illustrations in this manual may
vary slightly from the product
purchased. All images in this
manual are for reference purposes
only. Parts are not necessarily
pictured to scale.
1
2
4
5
7
3
6
8
9
10
12
11
13
