Getting Started (Cont.)
Base assembly
1. Set the base on the floor.
2. Unscrew the metal washer and base locking lever and remove it from the
bottom of the lower column.
3. Insert the lower column into the base, put the metal washer onto the black
weight.
4. Insert the threaded end of the locking lever into the hole of the washer and
through the base into the bottom of the lower column. Turn the locking lever
clockwise to secure and tighten the base to the lower column.
5. Insert the upper column into the top hole of the lower column and tighten the
column securing knob.
6. Place the fan body on the top of the upper column and tighten the body
securing knob.
Fan head assembly
1. Remove and discard the plastic sleeve on the motor shaft. Position the back
grille against the front of the motor housing through the motor shaft. Ensure
that the handle at the back of grille is facing up and that all guiding pegs on
the motor housing are lined up with cut-outs on the back grille.
2. Secure the back grille into place with the nut. Fasten the nut firmly onto the
motor housing by tightening it in a clockwise direction.
3. Install the fan blade onto the motor shaft with the cut-outs fitted.
4. Place the blade cap on the motor shaft after the blade.
5. Fasten the parts into place by tightening the blade cap in anticlockwise
direction.
6. Check the correct rotation of the blade.
7. Attach the front grille to back grille and fasten the grilles with the clamping
ring, using a screwdriver to tighten the screw to secure the fan head
assembly.
