13
When compared to the other methods of cooking, induction cooking
has a very slow level of ambient heat, thus makes cooking ventilation.
Finally, the vitro ceramic glass as a cooking surface barely becomes
hot and this makes cleaning much easier.
8. OPERATING THE TOUCH CONTROL
Graphics for control p anel of d ouble-radiant-zone (horizontal)
sensor touch temperature adjuster
:
1. Switch button
2. Cooking mode selection
3. Display of cooking mode and power le vel indicator
4. Temperature up button
5. Temperature down button
6. Lock button
7. Timer
8. Display of cooking timer in dicator
