EUROSTER 813 – USER MANUAL 6
Remove battery insulation before wiring
Wiring
The retractor on the back of the plastic housing is for clamping the unit on the Wall or Rail.
Follow the graphic description below when mounting the unit.
Insert a Flat-head screw-driver in the position as
shown above.
Tilt the screw-driver to the direction as shown
above to push down the retractor.
Mount/Remove the unit in surface-mount
Mount the provided
surface-mountbracket
on the wall.
Align the top of back plastic
housing with the top of the bracket.
Push down the retractor and
mount.
Push down the retractor
to remove the unit
off the bracket.
