EUROSTER 813 – USER MANUAL 9
4. Press to go to the next setting
G. Set/Adjust Operation setpoint and Hysteresis (Switching differential) in S3
(Thermostatic in Output B. Refer to the page of Specification Item-13 for a detailed
description)
1. Press or to choose the required S3 point
2. Press to go to the Hysteresis setpoint.
3. Press or to choose the required hysteresis setpoint
4. Press to go to the next setting.
(Effects in operating mode-2/ 3/ 4 only)
H. Offset – Temperature sensor’s calibration ( Refer to the page of specification
Item-15/16 for a detailed description)
1. Press or to choose the required temperature calibration value in S1.
2. Press for the calibration in S2.
3. Press or to choose the required value.
4. Press for the calibration in S3
5. Press or to choose the required value.
6. Press to set the next setting
(Calibration in S3 effects in operating mode-2 / 3 / 4 only)
I. Timer function (Refer to the page of introduction and the page of Specification
Item-14 for a detailed description, 2 program-periods are provided in this unit)
For setting the Timer, press and hold for fast forward press and hold for fast
backward
1. Press to enable the Timer function and to choose the required ON/OFF time in each
program.
2. Press or to choose the time for P-1 ON
3. Press to set the P-1 OFF time
4. Press or to choose.
5. Press to set the P-2 ON time
6. Press or to choose.
7. Press to set the P-2 OFF time.
8. Press or to choose.
(Timer function activates in Mode-2 or 3 only)
9. Press to go to the next setting
All internal settings are now completed, press to start operation.
When this unit is in operation, press or to check the temperature of each temperature
sensor.
Stand-by mode
1. Press .
2. A Flashing „YES” will show on the LCD.
3. Press again.
4. This unit is now manually turned off.
Remark:
When this unit was manually turned off, the build-in protective function will be automatically
