Operation and Maintenance Instructions
Table 5 - Recommended Recirculating Water Pump Sizing for Remote Sump Application - Coil Products Only
Notes: For dual cell units, the inlet pressure shown is per cell.
The spray water flows can be found in the bulletins of the respective models.
Evaporative Condenser
Model Number
Closed Circuit Cooler
Model Number
Required Inlet
Pressure (kPa)
eco-ATC ATC ATW, eco-ATW, eco-ATWE
- - 50E to 165E 0,9 m & 1,2 m wide 14
176 to 272 M170E to M247E 2,3 x 2,6 m 14
M208 to M302 M203E to M233E 2,4 x 2,7 m 14
M252 to M454 M252E to M439E 2,4 x 3,2 m / 3,7 m / 4,3 m 14
M411 to M604 M426E to M591E 2,4 x 5,5 m 21
M545 to M718 M523E to M679E 2,4 x 6,4 m 27,5
M600 to M903 M607E to M877E 2,4 m x 7,4 m / 8,6 m 14
M821 to M1206 M852E to M1179E 2,4 m x 11,0 m 21
M995 to M1384 M1046E to M1358E 2,4 m x 12,9 m 27,5
M503 to M906 M501E to M844E 4,9 m x 3,2 m / 3,6 m / 4,3 m 17
280 to 503 XE298E to XC462E 3 m x 3,6 m 25,5
559 to 1005 XE596E to XC925E 3 m x 7,4 m 25,5
365 to 705 XE406E to XC669E 3 m x 5,5 m 39
731 to 1411 XE812E to XC1340E 3 m x 11,0 m 39
433 to 942 428E to 892E 3,6 m x 3,6 m / 4,2 m / 5,5 m 24
866 to 1883 858E to 1784E 3,6 m x 7,4 m / 8,6 m / 11,0 m 17
867 to 1884 857E to 1783E 7,3 m x 3,6 m / 4,3 / 5,5 m 21
1908 to 3766 1879E to 3459E 7,3 m x 7,4 m / 8,6 m / 11,0 m 17
775 to 1023 791E to 967E 3,6 m x 6,1 m 24
1607 to 2043 1625E to 1925E 3,6 m x 12,3 m 24
1608 to 2044 1616E to 1915E 7,3 m x 6,1 m 22
2911 to 4086 2855E to 3714E 7,3 m x 12,3 m 22
C-ATC
181 to 373
362 to 504
C-ATW
67-3H to 133-6J
- -
17
21
LRC
25 to 72
76 to 114
108 to 183
190 to 246
188 to 379
LRW
1 m wide 7
1,5 m x 3,7 m 14
1,5 m x 4,6 m 14
1,5 m x 5,6 m 14
2,4 m x 4,6 m / 5,6 m 14
LSCE
36 to 80
90 to 120
135 to 170
185 to 385
281 to 1120
400 to 1610
LSWA
1,2 m x 1,8 m 10
1,2 m x 2,7 m 10
1,2 m x 3,6 m 10
1,6 m x 3,6 m / 5,5 m 14
2,4 m x 3,6 m / 5,6 m / 7,3 m / 11,0 m 21
3 m x 3,6 m / 5,6 m / 7,3 m / 11,0 m 17
ESWA
72-23H to 72-46K 21
96-23H to 96-46K 17
142-23H to 142-46K 24
144-23I to 144-46M 21
216-23J to 216-46S 17
PMCQ
316 - 1420 (3 m wide)
399 - 1786 (3,6 m wide)
21
24
