LSTE UNITS - 2,4 and 3 m WIDE UNITS
FILL CASING
SECTION
PAN SECTION
LSTB UNITS
MIGRATION
BAFFLE
ACCESS
DOOR
BEARING
SUPPORT
FAN HOUSING
MOTOR BASE
WATER OUTLET
CONNECTION
OUTLET HOOD
& STRAINER
FAN SCREENS NOT
SHOWN FOR CLARITY
DRIFT ELIMINATORS
FILL
WATER DISTRIBUTION
SPRAY BRANCH
WATER INLET CONNECTION
CASING
FILL SUPPORT CHANNEL
WATER DISTRIBUTION
SPRAY BRANCH SUPPORT
