Child Restraint Features
Seat Rotation
!
WARNING! DEATH or SERIOUS INJURY can occur.
NEVER use this child restraint in a vehicle seating position where it cannot be
secured tightly. A loosely installed child restraint will not protect your child in a crash.
When properly installed, the Revolve360 rotates in its
base, making it easy to safely load and unload your child.
To rotate the Revolve360, lift up on the Rotation Handle
at either side of the headrest and turn the seat to the
desired loading/unloading position. The Rotation Lock
Indicator will be RED.
When your child is securely harnessed, rotate the seat
either FORWARD-FACING or REAR-FACING based on
their size (pages 10 and 12) and release the Rotation
Handle. The Rotation Lock Indicator will be GREEN.
NOTE: The Revolve360 can only be rotated into
FORWARD-FACING mode in the most reclined position.
REAR-FACING
LEVEL INDICATOR
Bead must be located
within appropriate zone.
Vehicle MUST be on level ground.
Lower Connectors/UAS
Do not install
by this method
for a child
weighing more
than 15.9 kg
(35 lbs).
Lap/Shoulder Belt
Lap Belt
Always use tether strap
in rear facing installation.
P25809042 7/20
1.9 - 9kg (4 - 20 lbs)
Lower Connectors/UAS
Lap/Shoulder Belt Lap Belt
Always use tether strap in rear-facing installation.
Ball must be in proper
zone for child size:
Vehicle MUST be on
level ground.
25809042 10/20
9.1 - 18kg (20 - 40 lbs)
Do not install by
this method for a
child weighing
more than
15.9 kg
(35 lbs).
LEVEL INDICATOR
REAR-FACING ONLY
1.9 - 18 kg (4 - 40 lbs)
44 - 101 cm (17 - 40 in)
REAR-FACING
