Evenflo ExerSaucer Triple Fun User Manual

3
F
J
3. To install a pedestal C, hold it above the base F so that
the locking tab with the rib G lines up directly over the
slot with the notch H.
C
G
H
F
Stage 2 Base Assembly
4. Attach the spring D to the hook I on the base F, as
shown. Once the spring is in place, align all three locking
tabs J on the pedestal with the slots in the base and snap
the pedestal into place.
D
I
5. Turn the base F upside down and make sure the
locking tabs J on each pedestal C are completely pushed
through to the underside of the base F and have locked
over the edge of the openings, as shown.
6. Check to ensure that the locking tabs are installed properly
by turning the pedestal
C clockwise, then releasing.
The pedestal MUST spring back into place.
Repeat for all four pedestals.
F
C
J
C
C

Evenflo ExerSaucer Triple Fun Specifications

General

Stages	3
Material	Plastic, Fabric
Assembly Required	Yes
Seat Rotation	360 degrees
Removable Toys	Yes
Foldable	No
Height Limit	30 inches
Features	music, lights
Batteries Required	Yes
Care and Cleaning	Wipe clean with damp cloth
Dimensions	30 x 30 x 25 inches
Weight	15 lbs
