42
Removing the Lower Anchor
Connector Assembly System
1
When the lower anchor connector system is not in use,
you MUST securely store it on the base as shown using
the storage bars on the underside of the base. A loose
lower anchor connector strap and hook may injure your
child.
2
3
Press the tab and twist, then remove the hook from the
anchor.
The lower anchor connector assembly system that
comes with your child restraint will be one of the
two types below.
Tilt and slide the adjuster
to loosen the lower anchor
connector assembly.
Press the adjuster release
button to loosen lower
anchor connector
assembly.
To Next Page
