Evenflo REVOLVE360 User Manual

57
Lap/Shoulder Belt (Rear-Facing and Forward-Facing)
Installing Lap/Shoulder Belt (Preferred Method)
5. Squeeze handle on LockStrong
belt tensioner until lock indicator
turns RED, then lift up on belt
tensioner to allow access to the
belt path.
6. Route lap/shoulder belt through
belt path opening on window
side of base and feed through
opposite belt path opening. Push
Base against vehicle seat back.
BUCKLE THE BELT.

Evenflo REVOLVE360 Specifications

General

Type	Convertible Car Seat
Rotation	360-degree rotation
Rear-Facing Weight Capacity	4-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Harness	5-point harness
Headrest Positions	10
Safety Standards	FMVSS 213
Side Impact Protection	Yes
Machine Washable Cover	Yes
Installation	LATCH or seat belt
